注塑产品模具可行性分析(DFM).ppt
S401 Rear Frame DFMCAD version number：95_23335_A01Product informationREVDate Update or added slidersRemark: Segment : /Thickness :2MM Project name :S401 PM/PE/ Part name :Rear Frame DFM by:XIAO Part No:95_23335_A01 Checked by:qing 3D Rev95_23335_A01_-95_23335_A01_-_FRAME_REAR_CA_S401_3DORG_1_1_FRAME_REAR_CA_S401_3DORG_1_1_0_02250_0225产品尺寸产品尺寸 Product size：311.06*935.6*62.4Cavity and core ImpressionCavity CoreTool information Resin material : PP LGF 40 Resin supplier:Ticona Celstran PP-LGF 40-2 Resin Grade TonnageN/A Runner Sys:Hot runner No. of Hot Tip3 point HRS Or Synventive Tool type :2 plate Gate type :针阀式转冷流道进胶针阀式转冷流道进胶3 point valve gates turn to edge gate Automatic:YES No. of Gate. (Each part)3 Part weight (g) :666G Cavity steelS50C/1.2343 Forecast volume (shot)N/A Special tool :N/A Core steelS50C/1.2343 No. of Cavity:1 Cosmetic part (Y/N):N Slider steelS50C/1.2343 Family with:S401 Cosmetic finishingN/A Lifter and small insert steel1.2344Need your input and correction to below information:Customer comment. (please give your approval and comments)OK or NGremarkApproval by:dateShrinkageCustomer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: above shrinkage is estimated according to our understanding, pls correct it if there is any risk of getting right dimensionShrinkage with orientationXYZYX？Gate layoutCustomer comment. (please give your approval and comments)OK or NGremarkApproval by:date三点位置针阀式热嘴转搭底进胶 3 point valve gates turn to edge gatePart LayoutTool topNotes: this is very rough layout, but it is a Useful guidance for our tool designer.Need to show part layout to avoid customer misunderstood our proposal出模方向 Demolding directionBenchmark Location客户确认所有安装孔都是一个方向Parting line Customer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: please advice any concern on propose parting line.CorePLCavity 蓝色为PL线 Blue line is PL line.Customer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: please advice any concern on propose parting line.CavityPLCore Parting line 蓝色为PL线 Blue line is PL line.目前没有插穿角度，为简化分型面，此处做5以上插穿（左右两侧）This position do not have shut off angle. For To simplify the parting line, we suggest make 5 degree shut off shutoff angle. (Both side are the same)确认是否能更改（客户不能理解此处具体意思）；客户回复分型线有问题，都是放在最下面的，不会出现插穿面，乐新下来根据客户意见重新分析参考S301Parting line Customer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: please advice any concern on propose parting line.此处建议做3度左右减胶拔模，模具上需插穿 We suggest reduce plastic to increase the draft angle to 3 degree.Parting line Customer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: please advice any concern on propose parting line.蓝色为PL线 PL lineCustomer comment. (please give your approval and comments)OK or NGremarkApproval by:dateInsert lines of Cavity sideNotes: please advice any concern on propose parting line.前模镶件结构如示 Cavity side main inserts layout 软硬模前模镶件分型一样软硬模前模镶件分型一样 Soft tool and Hard tool are the sameInsert 1Insert 2Insert 3此区域要做成整块，要装配帘布，不能有分型线Customer comment. (please give your approval and comments)OK or NGremarkApproval by:dateInsert lines of Core side后模镶件结构如示 Cavity side main inserts layout 软硬模后模分软硬模后模分3件件Soft tool and Hard tool are the sameInsert 1Insert 2Insert 3Core Lifter & SliderCustomer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: please advice any concern on witness line form by lifter.后模行位1和2（左右两侧）Core side slider 1 ,2 and slider insert line (both side are the same)倒扣问题，PPT说明不清楚，乐新重新更新Core Lifter & SliderCustomer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: please advice any concern on witness line form by lifter.后模行位3 Core side slider 3 position and slider insert lines乐新重新更新PPT，需要客户确认的东西都要提出来是否需要客户确认，确认何种问题Customer comment. (please give your approval and comments)OK or NGremarkApproval by:dateThickness Analysis (shrinkage/strength/sink mark) 产品整体胶厚均匀Overall the part thickness even Draft angle information Cavity Core sideCavity side前模此处位置倒扣，需修改 These position have undercut need to modify产品周圈无出模斜度，建议减胶拔模出后模 This position around the Parts do not have demolding draft angle，need to modify Part Issue one Part Issue one客户下来检查数据Draft Analysis information-Core sideCavity sideCore side后模所有未拔模面建议减胶拔模1以上At the Core side， all these surface need reduce plastic make draft angle more then one degree. Part Issue two Part Issue two客户确认更改Cavity Lifter & SliderCustomer comment. (please give your approval and comments)OK or NGremarkApproval by:dateNotes: please advice any concern on witness line form by lifter.此处位置倒扣，为简化模具结构和生产稳定，建议修改。Undercut position need to modify建议修改成这种枕位可以成型的特征（左右两侧）Suggest modify like this (both are the same) Part Issue three Part Issue threePPT乐新更新得更详细，0.65此处模具上做枕位封胶太薄，而且此处C角和R角会产生薄钢，建议取消，加宽枕位封胶位置2MM以上This position is plastic too thin, that will lead to mold sharp steel. We suggest increase th
